How To Install Xschem In Debian, Ubuntu And Kali?

xschem

schematic capture program

Maintainer: Debian Electronics Team

Email: [email protected] .

Website: https://xschem.sourceforge.io/stefan/xschem.html

Section: electronics

Install xschem

Debian apt-get install xschem Click to copy
Ubuntu apt-get install xschem Click to copy
Kali Linux apt-get install xschem Click to copy

xschem

schematic capture program

Xschem is a schematic capture program, it allows creation of hierarchical representation of circuits with a top down approach. By focusing on interfaces, hierarchy and instance properties a complex system can be described in terms of simpler building blocks. A VHDL or Verilog or Spice netlist can be generated from the drawn schematic, allowing the simulation of the circuit. Key feature of the program is its drawing engine written in C and using directly the Xlib drawing primitives; this gives very good speed performance, even on very big circuits. The user interface is built with the Tcl-Tk toolkit, tcl is also the extension language used.

Installation of latest xschem command is available for Debian, Ubuntu and Kali. You can copy the command for your OS from above and paste it into your terminal. Once you run the command it will download the 2026 latest package from the repository and install it in your computer/server.
